Drop Forging - Introduction

What is drop forging?

Drop forging is a metal shaping process, the metal to be formed is first heated then shaped by forcing it into the contours of a die, this force can be in excess of 2000 tons. The drop forging process can be performed with the material at various temperatures;

  • Hot Forging

    During hot forging the metals are heated to above their recrystallization temperature. The main benefit of this hot forging is that work hardening is prevented due to the recrystallization of the metal as it begins to cool.

  • Cold Forging

    Cold Forging is generally performed with metal at room temperature below the the recrystallization temperature. Cold forging typically work hardens the metal.

There are two types of drop forging, open die and closed die.
Open die drop forging requires the operator to position the work piece while it is impacted by the ram. The die attached to the ram is usually flat or of a simple contour, most of the shaping is achieved by the operator physically positioning the work piece before each stroke of the ram. There are also special dies which can be used to cut the metal, form holes or notches. see more

Closed die drop forging comprises of a die on the anvil which resembles a mould, the ram which falls and strikes the top of the metal billet can also be equipped with a die. The heated metal billet is placed on the lower die while the ram drives down forcing the metal to fill the contours of the die blocks. see more


Drop Forging Diagram
Diagram of basic drop forging set up
